Facade Systems - VISS Basic TV/VISS Ixtra TV | Jansen

Share
  • Use

    Facade glazing
  • Applications

    Residential, commercial
  • Characteristics

    Support-free facade construction
  • Certification

    CE marking in accordance with EN 13830Coefficient of thermal transmittance Uf > 1.2 W/m2K | Tightness against heavy rain up to class RE1200 | Air permeability up to class AE | Resistance to wind load up to class 2 kN/m2 | Impact resistance up to class E5/I5 | TRAV

More about this product

With VISS Basic and VISS Ixtra, Jansen offers cost-effective and aesthetic system solutions for the support-free construction of facades. The design of the system is based on the tried-and-tested VISS system. This makes it possible to construct a wide range of facades, even with very large spans. The choice of the shape and material of the loadbearing construction is unrestricted.

Materials/Surface Finishes

  • Uncoated steel, suitable for hot-dip galvanizing, powder coating or stove-enameling
  • Stainless steel in combination with VISS Basic and VISS Ixtra

Support Structures

  • VISS Basic: commonly available hollow profiles, IPE sections etc.
  • VISS Ixtra: tailor-made, laser-welded, sharp-edged profiles

Construction Types

  • Mullion-mullion-transom construction
  • Mullion-transom-mullion construction
  • Welded and/or push-fit construction
  • Segmental glazing, concave and convex

Equipment

  • Combination of VISS Basic, VISS Ixtra beams and VISS system profiles
  • Structural glazing
  • Easy fixing of solar screening devices
  • Windows and doors within curtain walls

Special Technical Features

  • Face width from 50 mm
  • Depth of construction to meet structural engineering requirements
  • Thickness of infill elements, 6 - 70 mm
