Minimalist Window - Pivoting | Vitrocsa

  • Use

    Pivoting window
  • Applications

    Residential, commercial
  • Characteristics

    Opens vertically on a right, left or central pivot, anodized 25-micron aluminum alloy, natural finish, slim vertical profile, Swiss made, large glass doors, thermal insulation, security

1 Catalogs and Files

By downloading any file you agree to the Terms of Use, Privacy Policy and to the communication of your data to the brand from which you download catalogs and files.
The product has been saved to the folder: My Downloaded Products

Contact manufacturer


More about this product

Vitrocsa has developed innovative expertise in the domain of its creation, the minimalist window. The many systems and solutions developed in-house guarantee original products, all manufactured to Swiss Made quality standards.

The pivoting window system opens vertically on a right, left or central pivot. The structure for these minimalist window design is anodized 25-micron aluminum alloy, in a natural color finish. As an option, the thermolacquered or anodized versions are available in an infinite choice of colors. Locking and sealing are assured by a mobile rack blade or cylinder with key.


In fixed or pivoting options, the width of the vertical profile is 18 mm. Locking and sealing assured by a mobile rack blade or cylinder
with key.


The Vitrocsa pivoting system is available in two ranges:

  • TH+ / Thermal insulation and large surface areas
    Using 32 or 44 mm double or triple glazing, the TH+ range allows for pivoting window surfaces of up to 12 m². The excellent insulating properties of the profiles, in combination with the glass, enable current low energy consumption standards to be met.
  • 3001 / Flagship range
    The 3001 range allows for sliding window surfaces of up to 6 m² with 26 mm double glazing. The range, invented in 1996, is considered the brand’s flagship product, which launched the Vitrocsa name.

Finishes, Drainage Chamber and Test

With an anodized 25 micron natural or colored aluminum alloy structure, the thermolacquered version is available in an infinite choice of colors, also, all our products include drainage chamber and test.



Safety and Security

Vitrocsa meet the requirements and expectations of their clients while offering them the highest level of safety and security. Vitrocsa products meets the highest standards such as RC2. Various additional components are available to meet other safety and security requirements, such as:

  • Alarm directly integrated into our system
  • Closed leaf position monitoring
  • Glass breakage detector
  • Special burglary-resistant glass
