Casa Tierra / Serrano Monjaraz Arquitectos

  • 01:00 - 23 January, 2014
Casa Tierra / Serrano Monjaraz Arquitectos
Casa Tierra / Serrano Monjaraz Arquitectos, © Pedro Hiriart
© Pedro Hiriart

© Pedro Hiriart © Pedro Hiriart © Pedro Hiriart © Pedro Hiriart + 29

  • Architects

  • Location

  • Architect in Charge

    Juan Pablo Serrano O, Rafael Monjaraz F
  • Design Team

    Mayra Díaz Martínez, Edgar Velasco
  • Builder

    CONVEA
  • Structural

    Humberto Girón
  • Ilumination design

    Luis Lozoya, Brimare, Starco/Magg
  • Interiors

    Juan Pablo Serrano O., Stuarr, Roma
  • Area

    676.0 sqm
  • Project Year

    2012
  • Photographs

© Pedro Hiriart
© Pedro Hiriart

Text description provided by the architects. For the design of Casa Tierra (Earth House) the project was developed in order to be friendly with the surroundings and with a high energetic performance respecting all the premises in the Cumbres de Santa Fe master plan and establishing how the architects consider all the XXI century houses should be done. The project is supported on the conscience that has always been Serrano Monjaraz Arquitectos trade mark when developing architecture. As any other project it is adequate to the environment and also responds to the sustainable design regulations that have been increasing in the last years.

© Pedro Hiriart
© Pedro Hiriart

The construction system of Casa Tierra was done with Pressed Earth Blocks (PEB) made from soil of the same lot. This system was selected for being cost and energy efficient, fire and pest resistant, virtually soundproof, durable and structurally sound and aesthetically pleasing. PEB provides complete architectural freedom and is made from non-toxic readily available natural raw material. Compared to other systems, it is more flexible and does not affect the width of the walls. The soil was pressed with 3% of concrete and 7% of lime, being 90% of the material needed for the construction obtained directly from the lot.

© Pedro Hiriart
© Pedro Hiriart

Casa Tierra is an example of the rational use of all the resources and the total respect for the surrounding environment. In its design all the guidelines of the complex were followed and elements that characterize its urbanization, such as: natural stone, apparent concrete in grey, black and white shades were incorporated. The gardens around the house were integrated to the natural surroundings to create a complete atmosphere.

Floor Plan
Floor Plan
