UseInterior ceilings and wall systems
ApplicationsCommercial, institutional, healthcare, educational, cultural, corporate
CharacteristicsEnvironmental friendly, very high acoustic performance, various solutions for plenum access and demounting, high humidity solutions
Hunter Douglas Architectural's Veneered Wood Tiles & Panels range consists of acoustic ceiling and wall elements, made of an MDF core, covered with a wooden veneer. Available in standard panels, or design custom panel shapes, in a wide range of veneers, finishes, and perforations.
Veneered Wood Tiles & Panels are an environmentally friendly building product with endless possibilities. They offer a unique natural look, given by a careful selection of the species type, color, and structure. The natural growth patterns of each tree can be clearly seen in the veneer, including natural characteristics such as knots and outgrowth. Once the veneer is chosen, the panels will be produced according to the layout plan to ensure a perfect fit.
- Custom panel sizes for a made to measure solution
- Very high acoustics up to alpha w 0.95
- Create a hidden, high acoustic solution with the mini micro-perforation
- Various solutions for plenum access and demounting
- Available as a ceiling and wall solution
- Reaction to fire: by impregnating wood, a reaction to fire classification (EN13501-1) of B-s1,d0 can be achieved. For special applications, higher classifications can also be achieved.
High humidity solutions: due to a special treatment to the wooden panels, some wood species are perfectly suitable for humid areas, such as swimming pools.
The Veneered Wood Ceiling Tiles can be produced in any size up to 600x1200mm. Special sizes are available upon request. Depending on the required joint width and access requirements, there are four-panel types available.
- Classic - Visible joints
The Classic panel is a typical lay-in panel, which can be laid on a standard T15mm or T24mm grid. The side finish with a rabbet makes sure the panel stays in place.
- Modern - Semi concealed joints
The Modern panel, due to the special edge detail, only shows 4mm of the T24mm grid after assembly. Each panel can be easily removed downwards and allow full access to the plenum with a simple push.
- Prestige - Concealed joints
The Prestige system has a special edge finishes that ensure that the substructure is completely concealed. Every panel can still be removed, simply by lifting and tilting.
- Veneered Wood Wall Tiles
The Veneered Wood Wall Tiles can be produced in any size up to 600x1200mm. Special sizes are available upon request. Depending on the required joint width and access requirements, there are two-panel types available.
- Standard - Open joints
- Trend - Closed joints
Wood Species and Finishes:
Choose from more than 40 veneers to create the ideal ambiance and feel. From light to dark tones, there is a veneer for each design. Standard, the panels are provided with a transparent lacquer, but if a special look is required, special varnishes, staining or paint finishes are also possible.
For more information regarding the available colors, click here to see the complete Wood Species and Finishes Selector.
Please find more detailed information here.
