Roof System - Kalzip® DuoPlus E | Kalzip

  • Available in

  • Use

    Roof
  • Applications

    Educational, industrial, public, cultural, commercial, healthcare
  • Characteristics

    Thermal and acoustic insulation, efficient installation, variable fixing system

1 Product File

By downloading any file you agree to the Terms of Use, Privacy Policy and to the communication of your data to the brand from which you download catalogs and files.
The product has been saved to the folder: My Downloaded Products
Kalzip Logo

Contact manufacturer

Kalzip

Kalzip Logo

Contact manufacturer

Kalzip

More from Kalzip

Website Phone

More about this product

The Kalzip DuoPlus E System retains all the qualities and benefits of a standard Kalzip standing seam roofing system. This hybrid system combines high-density thermal insulation with compressible glass mineral fiber insulation.

Kalzip’s DuoPlus E and Duo E roof systems offer a cost-effective and technically sound solution to achieve roof U-values as low as 0.10 W/m²/K.

Kalzip DuoPlus E on timber/plywood Kalzip DuoPlus E on concrete substructure Kalzip DuoPlus E on trapezoidal steel deck
  1. Kalzip profiled sheets
  2. E-type clip with rotatable clip adapter
  3. DuoPlus rotatable clip rail
  4. High-density thermal insulation layer
  5. Vapor Control Layer
  6. Timber rafters and timber/plywood deck
  1. Kalzip profiled sheets
  2. E-type clip with rotatable clip adapter
  3. DuoPlus rotatable clip rail
  4. High-density thermal insulation layer
  5. Vapor Control Layer
  6. Concrete substructure
  1. Kalzip profiled sheets
  2. E-type clip with rotatable clip adapter
  3. DuoPlus rotatable clip rail
  4. High-density thermal insulation layer
  5. Vapor Control Layer
  6. Trapezoidal steel deck

Benefits & Features

  • Minimized thermal bridging
  • High thermal performance
  • Variable insulation thicknesses up to 345mm
  • Compatibility with all E-clip types and heights
  • Impressive sound insulation values up to R‘w = 56 dB (A), contingent on roof structure
  • Functional and integrated system components
  • Adaptable fixing system
  • Expedited installation thanks to integrated system components
  • Suitable for substructures constructed from steel trapezoidal profiles, concrete, and timber decks

Thermal Separation

The design concept of the Kalzip DuoPlus E and Kalzip Duo E roof systems involves a thermal separation between the outer roofing and the inner support structure. Various configurations are possible for the support structure, on which a suitable vapor barrier is applied. A layer of durable mineral wool or PIR/PUR insulation panels, with thicknesses of 100 or 140 mm, serves as continuous thermal separation.

On this thermal insulation, the specially designed rotary clip board E is secured to the steel trapezoidal profile beneath a shell or wooden substructure using approved fasteners. The primary function of this rotary clip is to distribute the external load from the clip to the thermal insulation and the underlying substructure.
