Window System - heroal W 72 | heroal

  • Available in

  • Use

    Window system
  • Applications

    Residential, Commercial, Office
  • Characteristics

    Energy saving, thermal insulation, sustainable, burglary resistant, air permeable, wind and rain impact resistant

1 Product File

By downloading any file you agree to the Terms of Use, Privacy Policy and to the communication of your data to the brand from which you download catalogs and files.
The product has been saved to the folder: My Downloaded Products
heroal Logo

Contact manufacturer

heroal

heroal Logo

Contact manufacturer

heroal

More from heroal

Website Phone

More about this product

heroal's heroal W 72 is an aluminum window system designed with sustainable features that help reduce energy and material consumption during manufacture and a building's lifetime. heroal W 72 window systems decrease energy costs while increasing a building's thermal efficiency.

Product Benefits

  • Sustainable window system
  • Suitable for commercial, residential, and office projects
  • Help increase energy savings
  • Soundproofing class 1-5
  • Durable and resistant to burglary, driving rain, and wind impact
  • Design freedom thanks to high-quality heroal hwr powder coating

Sizing - Profile Depth

Frame profile 72mm
Leaf profile 84mm
Bar profile 72mm

Sizing - Visible Profile Depth

Frame profile 50-250mm
Leaf profile 33-67mm
Sash/frame combination 90mm
Bar profile 74-254mm

Sizing - System Properties

Glass filling strength 66mm
Max. leaf weight 300kg
Max. leaf height 2.8mm
Max. leaf width 1.6mm
