Mitrex is a specialist in high-performance building-integrated photovoltaic (BIPV) systems that combine solar generation and façade aesthetics.
Mitrex presents the Cladify Prefab Wall System (CladiFab), a lightweight, prefabricated wall panel designed for rapid installation and architectural flexibility.
This system integrates thermal, air, water, and vapor barriers within structural composite panels, offering rainscreen performance, multiple finish options, and floor-by-floor installation without the need for cranes or heavy equipment.
Features:
- Prefabricated Efficiency: Panels are installed from inside the building, floor by floor, anchored to slab channels or engineered brackets, significantly reducing site work and installation time.
- Integrated Envelope Performance: Thermal, air, water, and vapor barriers are built directly into the panels, with a drainage system qualifying the assembly as a rainscreen for enhanced moisture and thermal control.
- Lightweight and Strong: Aluminum honeycomb core provides high out-of-plane compression and shear resistance while keeping panel weight low (4.52–5.28 lb/ft²).
- Architectural Flexibility: Surface finishes include PVDF-coated aluminum, stone, BIPV, porcelain, and brick, with custom options available for diverse design requirements.
- Rapid and Safe Installation: Prefabricated panels enable slab-to-slab installation without cranes or heavy equipment, minimizing disruption in high-rise or retrofit projects.
- Sustainability and Durability: Built from non-combustible materials and designed to last the lifetime of the building, supported by a lifetime warranty.
Specifications:
| Core thickness | 75 mm (3 in) or 100 mm (4 in) aluminum honeycomb |
| Panel size | Standard 3960 × 1060 mm; custom sizes available |
| Panel weight | 22.07–25.77 kg/m² |
| Surface options | PVDF-coated aluminum, stone, BIPV, porcelain, brick, custom finishes |
| Installation | Floor-by-floor prefabricated panels; slab-to-slab; integrated barriers; no heavy equipment required |
Applications:
The Cladify Prefab Wall System is suitable for a broad range of projects, including:
- Commercial Towers: Provides rapid, high-performance envelope installation for large-scale developments.
- Institutional Buildings: Supports complex building designs while ensuring integrated barrier performance and fire safety compliance.
- Residential Complexes: Lightweight and strong panels enable safe and efficient installation, ideal for both new construction and retrofits.
By combining architectural flexibility, integrated performance layers, and prefabricated installation, CladiFab meets modern construction demands for speed, sustainability, and long-term durability.
