Pivot Slide Folding Door System – Motion 60PS | Motion Facades

• Available in

• Use

  Door system

• Applications

  Residential, commercial

• Characteristics

  Thermal insulation, 5 maximum locking points, minimal sliding, super slim, small mullion width

• Sizes

  Maximum 3 meters

Contact manufacturer

Motion Facades

Contact manufacturer

Motion Facades

More from Motion Facades

Website Phone Send Message

More about this product

Kinetic Facades presents Motion 60PS, a minimal folding door system with thermal insulation properties.

Technical Characteristics

Bottom track height	55 mm
Floor step	0 / 12 / 43 / 55 mm
Frame height, horizontal top	65 / 88 mm
Frame height, vertical	64 mm
Frame width	74 mm
Tile insert	20mm
Floor typology	Step, Submerged
Riding typology	Bottom Rolling
Sliding / Alignment rollers	Stainless Steel
Sash height, vertical	36 mm
Sash height, horizontal	36 mm
Sash width	60 mm
Centre mullion height	86 mm
Max. weight per sash	300 Kg
Max. sash width	2000 mm
Max. sash height	4000 mm
Opening type	Pivot Slide
Glazing width possibilities	32 / 45 mm
Maximum locking points	5
Sealing type	4 Gaskets
Fabrication thermal transmittance	≥1.0 W/(m2K)
