Trimoterm FTV in the BASE - Backing wall | Trimo

Share
  • Use

    Backing wall façade system
  • Applications

    Corporate, commercial, cultural, industrial
  • Characteristics

    High-quality fireproof and sustainable product with 99% recyclability

3 Supplementary Files

The product has been saved to the folder: My Downloaded Products

More about this product

Brand new BASE as Trimo Backing-wall Insulated Facade System solution guarantees true architectural expression as a main structural carrier wall for various final cladding. The first fully tested mineral wool cored panel for Backing-wall system including optimized details design was done for the mechanical behaviour in collaboration with the independent institutions; iS-engineering GmbH and Technische Universität Darmstadt, Germany - Institute for Steel Construction and Materials Mechanics for testing.

The robust single-span system works as a load-bearing wall, where an additional final cladding is fixed through the Omega steel profiles. The internal steel sheet of the panels remains intact, as the Omega steel profiles are fixed only on the external steel sheet. The system is flexible and modified for the building for horizontal or vertical installation.

For more information see the Supplementary Files.

Key benefits of Trimoterm FTV Backing-wall Insulated Façade System

COMPATIBILITY

Trimoterm FTV backing wall insulated facade system enables various final cladding and can achieve a load capacity of up to 60 kg/m² in extreme conditions.

VENTILATED FACADE FUNCTION

Trimoterm FTV backing wall insulated facade system with additional cladding works as a ventilated facade and does not require additional waterproof membranes, vapor, and wind barriers.

FLEXIBLE FAST INSTALLATION

The flexibility and simplicity of the Trimoterm FTV backing wall insulated facade system enable its fast installation in a horizontal or vertical direction.

SMOOTH AND FLAT INTERNAL SURFACE

Trimoterm FTV backing wall insulated facade system enables smooth flat internal surface due to fixing substructure omega profile just on load-bearing external steel sheet.

PREFABRICATION

Certified Trimoterm FTV product for backing wall insulated facade system is prefabricated and produced in a controlled environment and ensures loadbearing capacity.

STABLE CLIMATE

Trimoterm FTV backing wall insulated facade system provides a stable climate with the best airtightness and water tightness in the market, exceptional thermal transmittance and guarantees the safety of people and goods with reaction to fire classification A2-s1, d0.

OPERATING TIME

Trimoterm FTV backing wall insulated facade system enables replacement of the final cladding during the operating time of the building.
