Shiplapped Edge Profiled Ergo Board | EGGER

Share
  • Use

    Partition walls, Interior and dry construction
  • Applications

    Residential, Commercial
  • Characteristics

    Low weight of < 12 kg, circumferential innovative edge profiling with shiplap and tongue and groove, printed nail grid on the top, formaldehyde-free glued, verified fire resistance duration of 30 to 90 minutes, noise protection between 40 dB to 65 dB, high stability, surfaces ready to be painted, installation on metal and wooden stud frames

Supplementary Files

Ask for more information / Quote
You have to type a valid name
You have to type a valid email format
You have to type a valid phone number
You have to type a message longer than 10 characters
I want to receive a sample
By sending this quote request you agree to the Terms of use and the Privacy Policy.

More about this product

The EGGER Ergo Board is an edge profiled construction board, which has been especially developed for drywall construction. Thanks to its low weight of < 12 kg and a special shiplap profiling, this one-man panel offers straightforward handling for installation that is up to 30% faster as compared to standard boards. The product has high structural strength and is formaldehyde-free glued. These properties make the board the ideal wood-based material for interior applications.

CELUM: 252885

Benefits:

  • A real one-man panel
  • Endless installation
  • Straightforward placement and positioning
  • Better work result
  • Used for a wall height of up to 5 m in the classes EK 1 and EK 2
  • Verified construction for increased fire protection requirements of up to F90 / EI90

Ready-to-use wall coverings made of plasterboard or decorative surfaces made from EGGER Eurodekor or EGGER Compact Laminate can be effortlessly fastened to the EGGER Ergo Board regardless of the grid of the substructure.
