Pekapeka House / Parsonson Architects
© Simon Devitt
Architects: Parsonson Architects
Location: Pekapeka Beach, New Zealand
Project Team: Gerald Parsonson, Tim Lovell
Structural Engineer: Spencer Holmes Consulting Engineers
Builder: Northface Construction
Project Area: 156 sqm
Project Year: 2008
Photographs: Simon Devitt
This holiday home is an exploration in how to create a building of both a strong architectural character and economy.
floor plan
© Simon Devitt
We have used simple modular construction techniques combined with a very simple form. The plan is a rectangle and is divided into 3 parts, the solid bedroom forms at each end support a floating roof over the living space in between.
© Simon Devitt
© Simon Devitt
This layout allows the living room to face both east to hills and west to the sea. It allows sun into the house throughout the day, for passive solar heating of the concrete slab and creates a sheltered outside space on the east side that still keeps a strong connection to the western sea views.
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- © Simon Devitt
-
- floor plan
-
- northwest elevation
-
- southeast elevation
-
- northeast & southwest elevations
-
- section 01
-
- sections 02
