Motion Facades' minimal sliding system is engineered for large panels in exclusive commercial and residential buildings where high thermal insulation is required. This type of sliding system is perfect for spaces where a clean, minimal aesthetic is desired.
The Motion 51 / 51 Plus system works by tracking parallel panels with stainless steel wheels and running guides for seamless sliding movement and durability. Its design also includes top alignment rollers—important for panels wider than 2 meters.
Specifications
Maximum sash height | 4 m |
Maximum sash width | 3 m |
Maximum weight per sash | 600 kg |
Glazing width possibilities | 32 mm |
Maximum locking points | 6 |
Frame height | 42 mm |
Frame width | 62 / 33 / 205 / 276 mm |
Floor typology | Step, submerged |
Riding typology | Hovering, semi-submerged |
Sash height, vertical | 20 / 30 mm |
Sash height, horizontal | 38 / 53 mm |
Sash width | 47 mm |
Center mullion visible height | 16-20 mm |
