Shade Fabric - Mermet E and M Screen Chroma | Draper

Share
  • Use

    Solar shading
  • Applications

    Commercial
  • Characteristics

    Metalized fabric, scratch resistance, high solar reflectance, glare control, thermal comfort, view-through, energy efficiency
  • Certification

    GREENGUARD Gold Indoor Air Quality, RoHS Compliant (free of heavy metals), Fire Retardant (NFPA 701-10 TM#1), (California U.S. Title 19, and CAN/ULC-S109 Small & Large Scale), Fungal Resistant (ASTM G21), and Bacterial Resistant (ASTM E2180)
  • Guarantee

    10 Year Interior Warranty
Ask for more information / Quote
You have to type a valid name
You have to type a valid email format
You have to type a valid phone number
You have to type a message longer than 10 characters
By sending this quote request you agree to the Terms of use and the Privacy Policy.

More about this product

Draper E Screen Chroma™ and M Screen Chroma™ are high-performance shade fabrics for commercial projects. Created as a spring collection the window shading fabrics were created to fill the market need for more durable metalized fabrics, as well as shade materials with minimal ingredients and additives.

E Screen Chroma™ and M Screen Chroma™ are unique with their new proprietary and aluminum back-coating for improved scratch resistance and higher solar reflectance. This enhanced metalized layer also provides a hydrophobic finish to repel water and oils for better durability, providing new flexibility for installations in humid climates, unlike other metalized fabrics. Both products are available in a 3 percent openness and have a unique construction of fiberglass core yarns and metal finishing, enabling the fabrics to deliver excellent glare control, thermal comfort, and view-through.

E Screen Chroma™ M Screen Chroma™
E Screen Chroma™ has the same room side basketweave appearance of traditional E Screen™ from Draper, yet it achieves a higher solar reflectance rating of up to 82 percent with a 63 percent improvement on solar heat gain coefficient (SHGC). This high-performance option of the E Screen™ line can be used in conjunction with Mermet’s traditional E Screen™. M Screen Chroma™ maintains the popular rib-weave construction of Draper's standard M Screen™, but with a higher solar reflectance rating of up to 86 percent with a 68 percent improvement on SHGC. This high-performance option of the M Screen™ line can also be used in conjunction with traditional M Screen™ for a seamless design, maximum energy efficiency and cost savings.

Specifications

E Screen Chroma™ M Screen Chroma™
Fabric Style Basketweave Rib Weave
Composition 36% Fiberglass | 64% Vinyl Ultra-fine layer of aluminum 36% Fiberglass / 64% Vinyl, Ultra-fine layer of aluminum
Openness Factor 3% 3%
UV Blockage Approximately 97% Approximately 97%
Width 94.5 in (240 cm) 112 in (285 cm)
Weight 11.92 oz/yd2 (404 g/m2)±5% 12.0 oz/yd2 (405 g/m2) ±5%
Thickness 0.020 in (0.50 mm) ±5% 0.018 in (0.46 mm) ±5%

Colors

  • E Screen Chroma™
    • White/Linen
    • White/White
    • White/Pearl
    • Charcoal/Pearl
    • Charcoal/Charcoal
  • M Screen Chroma™
    • Charcoal/Sable
    • White/White
    • White/Linen
    • Pearl/White
    • Pearl/Pearl
    • Charcoal/Grey
    • Charcoal/Charcoal
