PH38 - Sliding | PanoramAH!
Navigate products using your keyboard
  1. ArchDaily
  2. Products
  3. Windows
  4. PH38 - Sliding

PH38 - Sliding | PanoramAH!

Share in Whatsapp
  • Use

    External partitions
  • Applications

    Residential, Commercial, Restaurants, Hotels, Corporate
  • Characteristics

    Aluminum casement system, self supporting glass, limitless number of rails, thermal insulation up to 1.165 W/m².K, Sound Insulation: 41 dB, Locks: one point latch; multipoint locking system, Maximum Area Panel: 19m2.
  • Format

    Sliding
  • Sizes

    Maximum Area Panel 19m2; 20mm vertical profiles
  • Certification

    ISO 9001:2015 Quality Certified

Supplementary Files

Ask for more information / Quote
You have to type a valid name
You have to type a valid email format
You have to type a valid phone number
You have to type a message longer than 10 characters
I agree to the Terms of use and the Privacy Policy.

More about this product

PanoramAH! Minimal Frame Window PH38 is a sliding aluminium casement system that challenges the structural properties of glass, enabling the execution of large glazed areas with the use of vertical, minimal (slender) aluminium profiles. Unlike traditional casement systems, glass is PanoramAH!’s self-supporting, main component, while the aluminium frame takes on the secondary functions of guiding its sliding motion, providing additional structural reinforcement and ensuring the window’s sealing capacity.

In this case, PanoramAH! presents Sliding, a system where multiple window panels may be opened simultaneously, through sliding sashes installed in up to 8 rails, allowing several configurations resulting in large openings. Most windows are limited by their own stationary panels, sliding only one panel behind the other. PH38 Sliding, however, allows for greater extensions of openings, challenging the traditional fashion of interior - exterior division.

undefined

PH38 Sliding allows several configurations in order to adapt to the requirements of each project; it may open from the side or from the center, duplicating the size of the resulting open space. Combination with pockets is also possible.
