Solarlux GmbH has been a specialist in flexible window and facade solutions for over 40 years. Their internal partition door range enables flexible room divisions and optimizes light transmission.
SL 45 Flexa partition wall system
 | |
| The SL 45 Flexa is an aluminium bi-folding partition wall for interior use. It adapts the SL 45 system for flexible room division, with multiple opening configurations and the option to create segmented floor plans. Panels fold fully to the side to create an unobstructed opening. | |
| Material | Aluminium |
| System type | Bi-folding partition wall |
| Accessibility | Range of floor track variants |
| Resistant to repeated opening and closing | In accordance with DIN EN 12400 |
| Insulation | non-insulated |
| Sight lines | Frame 5–64 mm Panel 55 mm Panel butt joint 117.5 mm Frame building depth: 45 mm Panel building depth 45 mm |
SL 60-HSW Flexa partition wall system
 | |
| The SL 60-HSW Flexa is a thermally insulated horizontal sliding wall that allows each panel to slide and lock in place individually, and segment space according to diverse requirements. | |
| Material | Aluminium |
| Versatility | The panel storage bay can be positioned anywhere within the system |
| Thermal transmission coefficient | 1.51 W/m²K |
| Glazing | 5 – 40 mm |
| Air permeability | Class 2 |
| Resistant to repeated opening and closing | In accordance with DIN EN 12400 |
| Sight lines | Frame: 2 – 115 mm Panel/panel butt joint: 60 mm/131 mm Overall frame depth: 65/80 mm Overall panel depth: 59 mm |
 | |
| Ecoline Flexa partition wall system is designed to provide flexible room divisions, featuring a slim design with a depth of 67 mm and a sight line of 99 mm at the panel joints. Its large glass area allows ample daylight to enter, ensuring organizational and acoustic separation without sacrificing natural light. | |
| Material | Aluminium |
| Panel joint | 99 mm |
| Depth | 67 mm |
| Accessibility | Range of floor track variants |
| Resistant to repeated opening and closing | In accordance with DIN EN 12400 |
